Gurit® Corecell™ S

GURIT® CORECELL™ S
STRUCTURAL FOAM CORE

    • Sub-sea buoyancy foam
    • High hydrostatic crush strength and water resistance
    • Outstanding mechanical properties
    • Ultra-fine cell size
    • Lower density than resin-based syntactics
    Gurit® Corecell™ S has been designed specifically for use in sub-sea buoyancy applications. Its resistance to crushing means that it can withstand depths of over 2700m, and its closed-cell structure gives it a high water resistance that ensures buoyancy is maintained over time. With its very high compressive strength, Gurit® Corecell™ S can also replace other materials, such as plywood, when creating high strength inserts for through-bolting in composite laminates.

    Technical Excellence

    Having the smallest cell size of all the Gurit® Corecell™ products, Gurit® Corecell™ S absorbs very little resin in lamination processes, thus minimising weight gain. The small cell size and the product’s inherent toughness also contribute to the excellent machineability of Gurit® Corecell™ S. Complex shapes can be created in Gurit® Corecell™ S using a variety of milling, routing, sawing and drilling techniques.

    Gurit® Corecell™ S is available at lower densities that can be achieved with a syntactic, with standard products ranging from 210 to just over 450kg/m3.
